- High Positioning Accuracy: With about of 50 centimeters positioning, it can search 20 satellites within a few seconds at the open ground.
- De-interference and Anti-interference: Two-stage filtering with 78db attenuation effectively filters out-of-band interference. In-band input 1dB compression point -3dBm high linear LNA can minimize the impact of even a small amount of interference signals that pass the filter. Effectively resist strong signal interference, such as high-power image transmission on drones, high-voltage lines, etc.
- Excellent Performance: 50 centimeters positioning accuracy, positioning 20 satellites in 6 seconds at open ground, and station-keeping capability even at the valley bottom. Support multiple positioning systems GPS, GLONASS L10F, QZSS L1 C/A, BeiDou B1, the dual-mode operation is available
- Top Configuration: GPS decoder chip: Radiolink TS100, with Ublox M10050, is much better than a single GNSS 7N. Built-in high-precision electronic compass IST8310(I2C port). Antenna: 2.5dbI high gain and selectivity ceramic chip antennas. Double Filter: two-stage SAWF (Surface acoustic wave filter) from Murata.
- Super Mini Size: only 1.26*1.18*0.47", 20g(0.71oz), 6pin connector compatible with Radiolink mini pix, crossflight flight controller, the connector can be changed for other brand flight controller.
