- Advanced Navigation Technology: Powered by the UBLOX M9 chip with a native 25Hz update rate, ensuring fast, precise positioning.
- Four-Star Positioning Support: Concurrent tracking across GPS, Galileo, Beidou, Glonass, and QZSS with up to 32 satellites for maximum coverage and reliability.
- Integrated QMC5883L Compass: Features a built-in geomagnetic compass for enhanced directional accuracy and stability.
- High-Performance Antenna: Equipped with a 25x25x4mm imported tri-band ceramic antenna, delivering strong signal gain and consistent performance.
- Wide Compatibility and Reliability: Designed for mid-to-high-end drones, unmanned vehicles, and ships, with exceptional operating ranges and robust environmental durability (-40°C to 85°C).
The AERO SELFIE GPS Module is a cutting-edge navigation solution for UAVs, drones, and unmanned vehicles. Powered by the advanced UBLOX M9 92-channel chip, it provides precise positioning with a 25Hz update rate. It supports concurrent tracking across GPS, Galileo, BeiDou, Glonass, and QZSS systems, allowing up to 32 satellites for maximum coverage and reliability. The integrated QMC5883L geomagnetic compass enhances directional accuracy, while the 25x25x4mm tri-band ceramic antenna ensures superior signal stability and gain. With low power consumption (80mA at 5V) and a wide operating temperature range of -40°C to 85°C, the MG-902 is ideal for demanding environments. It is perfect for mid-to-high-end UAVs, unmanned vehicles, and ships. Compact and robust, this module offers exceptional performance, setting the standard for single-point GPS solutions with unmatched accuracy and reliability in both ideal and challenging conditions.
- Package Dimensions : 4.53 x 3.58 x 1.06 inches; 0.42 ounces
- Date First Available : December 18, 2024
- Manufacturer : Shenzhen Ruijie Innovation Technology Co.,Ltd
- Country of Origin : China
